ZFIN ID: ZDB-FIG-091117-6
Malicki et al., 1996 - Mutations affecting development of the zebrafish retina. Development (Cambridge, England)   123:263-273
ADDITIONAL FIGURES
PHENOTYPE:
Fish:
Observed In:
Stage: Prim-25

Fig. 2

Phenotypes of mutants characterized by eye specific pigmentation defect. (A) At 36 hpf pigmentation is apparent both in the eye and skin of wild-type embryos. In (B) glass onion (glo)m117, (C) oko meduzy (ome)m98, (D) heart and soul (has)m129 and (E) nagie oko (nok)m227, we observed abnormal differentiation of the pigmented epithelium. Melanocytes of these mutants have normal appearance although their development may be somewhat delayed. (F) Wild-type and (G) omem98 pigmented epithelium in living embryos. The eye pigmentation is uniform in the wild type and patchy in the mutant. Arrowheads indicate position of the choroid fissure. In all panels dorsal is up and anterior left.

Gene Expression DetailsNo data available
Antibody Labeling Details No data available
Phenotype Details
Fish Conditions Stage Phenotype
cdh2m117/m117(AB) standard conditions Prim-25 brain disorganized, abnormal
Prim-25 brain shape, abnormal
Prim-25 eye pigmentation disrupted, abnormal
Prim-25 melanocyte differentiation delayed, abnormal
Prim-25 post-anal tail morphogenesis disrupted, abnormal
Prim-25 post-vent region morphology, abnormal
Prim-25 retinal pigmented epithelium poorly differentiated, abnormal
Prim-25 whole organism curved ventral, abnormal
crb2am98/m98(AB) standard conditions Prim-25 brain shape, abnormal
Prim-25 eye pigmentation disrupted, abnormal
Prim-25 melanocyte differentiation delayed, abnormal
Prim-25 retinal pigmented epithelium patchy, abnormal
Prim-25 retinal pigmented epithelium poorly differentiated, abnormal
mpp5am227/m227(AB) standard conditions Prim-25 brain shape, abnormal
Prim-25 eye pigmentation disrupted, abnormal
Prim-25 melanocyte differentiation delayed, abnormal
Prim-25 retinal pigmented epithelium patchy, abnormal
Prim-25 retinal pigmented epithelium poorly differentiated, abnormal
Prim-25 whole organism curved ventral, abnormal
prkcim129/m129(AB) standard conditions Prim-25 brain shape, abnormal
Prim-25 eye pigmentation disrupted, abnormal
Prim-25 melanocyte differentiation delayed, abnormal
Prim-25 retinal pigmented epithelium patchy, abnormal
Prim-25 retinal pigmented epithelium poorly differentiated, abnormal
