Fig. 1

Lateral views of zebrafish fzd2, 6, 7a, 7b, and 8a mRNA expression at 2, 3, and 4 days post-fertilization (dpf). (A–C) fzd2 is expressed within the pharyngeal arches (arrowheads), throughout the head and within the pectoral fin bud (asterisks in A,B). (D–F) fzd6 is expressed within the pharyngeal arches (arrowheads), throughout the head, within the posterior lateral line (arrows in D–F) and within the pectoral fin bud (asterisks in D–E). (G–I) fzd7a is expressed within the pharyngeal arches (arrowheads), in the brain and within the pectoral fin bud (asterisks in G–H). (J–L) fzd7b is expressed within the pharyngeal arches (arrowheads), in the anterior and posterior lateral line (arrows in J–L) and within the pectoral fin bud (asterisks in J–K). (M–O) fzd8a is expressed within the pharyngeal arches (arrowheads) and in the anterior and posterior lateral line (arrows in M–O). (M) At 2 dpf fzd8a is also expressed within the midbrain.

Expression Data

Genes:	fzd2 fzd6 fzd7a fzd7b fzd8a
Fish:	AB
Anatomical Terms:	anterior lateral line brain head midbrain pectoral fin pharyngeal arch posterior lateral line
Stage Range:	Long-pec to Day 4
Probe:	MGC:55191
