FIGURE

Fig. 3

ID

ZDB-FIG-080411-26

Publication

Pagnon-Minot et al., 2008 - Collagen XV, a novel factor in zebrafish notochord differentiation and muscle development

Other Figures

All Figure Page

Back to All Figure Page

Fig. 3

Immunostaining of frozen cross-section of 48 hpf wild type (A) and Col15a1-MO (B) zebrafish embryos using antibodies against mouse collagen XV NC8 domain. (A) In wild type, collagen XV is deposited around the notochord in the peri-notochordal sheath. A labelling is also observed in the skin. (B) Collagen XV immunostaining is completely extinguished in collagen XV morphants attesting for the morpholino efficiency. Note that staining persists in skin. Magnification: x 400.

Expression Data

Gene:	col15a1a
Fish:	WT WT + MO1-col15a1a
Knockdown Reagent:	MO1-col15a1a
Anatomical Terms:	integument notochord
Stage:	Long-pec

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 316(1), Pagnon-Minot, A., Malbouyres, M., Haftek-Terreau, Z., Kim, H.R., Sasaki, T., Thisse, C., Thisse, B., Ingham, P.W., Ruggiero, F., and Le Guellec, D., Collagen XV, a novel factor in zebrafish notochord differentiation and muscle development, 21-35, Copyright (2008) with permission from Elsevier. Full text @ Dev. Biol.
