FIGURE

Fig. 3

ID

ZDB-FIG-080114-21

Publication

Schneider et al., 2008 - Calcium fluxes in dorsal forerunner cells antagonize {beta}-catenin and alter left-right patterning

Other Figures

All Figure Page

Back to All Figure Page

Fig. 3

The DFCs are specified and migrate to the tailbud in thapsigargin-treated embryos. sox17 expression at 80% epiboly in (A) wt and (B) thapsigargin-treated embryos. Enriched Ntl protein at 80% epiboly in the DFCs in (C) wt and (D) thapsigargin-treated embryos; arrowheads note the DFC region. Expression of sox17 at 4-5 somites in (E) wt and (F) XeC-treated embryos; asterisks indicate dispersed cells, arrows indicate DFC/KV region. Tg (Dusp6:d2EGFP) expression at 80% epiboly in (G) untreated and (H) thapsigargin-treated embryos; arrows indicate DFCs. EGFP expression at tailbud to 1-somite in (I) untreated and (J) thapsigargin-treated embryos and at 5 somites in (K) untreated and (L) thapsigargin-treated embryos. XeC, Xestospongin C; n, notochord.

Expression Data

Gene:	sox17
Fish:	WT
Conditions:	chemical treatment: thapsigargin chemical treatment: xestospongin C
Anatomical Terms:	forerunner cell group Kupffer's vesicle
Stage Range:	75%-epiboly to 5-9 somites

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Development
