ZFIN ID: ZDB-IMAGE-131024-16
Figures for Kamel et al., 2013


Figure Caption/Comments:

Fig. 7 edn1 is required for expression of wnt9a, frzb and fzd7a. Lateral views at 55 hpf (A–F). Wholemount RNA in situ hybridization for wnt9a (A, B), frzb (C, D), fzd7a (E, F) and bapx1 (G, H) in wildtype and edn1-/- mutants. Expression of wnt9a, frzb and bapx1 was absent in the developing pharyngeal arches (B, D, H), while fzd7a expression was strongly reduced in both the forebrain and arches (F) in edn1-/- mutants.

Figure Data:
ZFIN wishes to thank the journal for permission to reproduce figures from this article. Please note that this material may be protected by copyright.
