Fig. 3

ID
ZDB-IMAGE-111117-24
Genes
Source
Figures for Korzh et al., 2011
Figure Caption

Fig. 3

Morphogenesis of the gastrointestinal epithelium in ihha-/- mutant. A, B, Expression of endodermal marker gata6 at 32 hpf. C, D, Expression of foxa1 along the pharynx, esophagus, intestina, swimbladder and liver epithelium at 50 hpf. Note a reduced endoderm in the absence of Ihha signaling. E, F, At 60 hpf foxa2 is expressed in the pharynx, esophagus, swimbladder, pneumatic duct, intestine, and floor plate. foxa2 expression is not affected along the floor plate in ihha-/- mutant, but reduced in endodermal domains, A–F, whole mount. G, H, Cross sections of foxa2 expression revealed reduced epithelium of the intestine and swimbladder in ihha-/- compared to control embryos at 60 hpf. I, J, Expression of the enterocyte marker ifabp along gastrointestinal tract is altered in ihha-/- at 74 hpf. K, L, In control larvae strong expression of ifabp is in the apical aspect of the gastrointestinal epithelium demonstrating epithelial differentiation, which is less obvious in ihha-/-. Abbreviations: e, epithelium; L, liver; ph, pharynx; pd, pneumatic duct; es, esophagus; g, gut; ph, pharynx; s, somites; sb, swimbladder; n, notochord. Numbers represent anterior somites. Scale bars: 250 μm.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 359(2), Korzh, S., Winata, C.L., Zheng, W., Yang, S., Yin, A., Ingham, P., Korzh, V., and Gong, Z., The interaction of epithelial Ihha and mesenchymal Fgf10 in zebrafish esophageal and swimbladder development, 262-76, Copyright (2011) with permission from Elsevier. Full text @ Dev. Biol.
