ZFIN Image: Sisson et al., 2009, Fig. 1


Figure Caption

Fig. 1 Lateral views of zebrafish fzd2, 6, 7a, 7b, and 8a mRNA expression at 2, 3, and 4 days post-fertilization (dpf). (A–C) fzd2 is expressed within the pharyngeal arches (arrowheads), throughout the head and within the pectoral fin bud (asterisks in A,B). (D–F) fzd6 is expressed within the pharyngeal arches (arrowheads), throughout the head, within the posterior lateral line (arrows in D–F) and within the pectoral fin bud (asterisks in D–E). (G–I) fzd7a is expressed within the pharyngeal arches (arrowheads), in the brain and within the pectoral fin bud (asterisks in G–H). (J–L) fzd7b is expressed within the pharyngeal arches (arrowheads), in the anterior and posterior lateral line (arrows in J–L) and within the pectoral fin bud (asterisks in J–K). (M–O) fzd8a is expressed within the pharyngeal arches (arrowheads) and in the anterior and posterior lateral line (arrows in M–O). (M) At 2 dpf fzd8a is also expressed within the midbrain.

Figure Data

Expression / Labeling details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 9(7), Sisson, B.E., and Topczewski, J., Expression of five frizzleds during zebrafish craniofacial development, 520-527, Copyright (2009) with permission from Elsevier. Full text @ Gene Expr. Patterns
