ZFIN ID: ZDB-FIG-191230-977
Suzuki et al., 2019 - Characterization of biklf/klf17-deficient zebrafish in posterior lateral line neuromast and hatching gland development. Scientific Reports   9:13680 Full text @ Sci. Rep.
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Anatomical Term:
Stage: Bud
PHENOTYPE:
Fish:
Observed In:
Stage: Bud

Figure 6

The expression of polster genes in the klf17-deficient embryos at the bud stage. The expression of polster markers he1.1 (a,b), ctsl1b (c,d), cd63 (e,f) and klf17 (g,h) was examined by WISH at the bud stage. (a,c,e,g) Wild-type embryos (klf17+/uy23). (b,d,f,h) klf17-deficient embryos (klf17uy23/uy23). Lateral view, anterior left. Arrowheads indicate the position of the polster. After taking pictures, genotyping of individual embryos was performed by genomic PCR. Scale bar, 200 μm.

Gene Expression Details
Gene Antibody Fish Conditions Stage Qualifier Anatomy Assay
cd63 klf17uy23/+ standard conditions Bud polster ISH
klf17uy23/uy23 standard conditions Bud Not Detected polster ISH
ctslb klf17uy23/+ standard conditions Bud polster ISH
klf17uy23/uy23 standard conditions Bud Not Detected polster ISH
he1.1 klf17uy23/+ standard conditions Bud polster ISH
klf17uy23/uy23 standard conditions Bud Not Detected polster ISH
klf17 klf17uy23/+ standard conditions Bud polster ISH
klf17uy23/uy23 standard conditions Bud Not Detected polster ISH
Antibody Labeling Details No data available
Phenotype Details
Fish Conditions Stage Phenotype
klf17uy23/uy23 standard conditions Bud polster cd63 expression absent, abnormal
Bud polster ctslb expression absent, abnormal
Bud polster he1.1 expression absent, abnormal
Bud polster klf17 expression absent, abnormal
