ZFIN ID: ZDB-FIG-160817-9
Kimelman, 2016 - A novel cold-sensitive mutant of ntla reveals temporal roles of Brachyury in zebrafish. Developmental dynamics : an official publication of the American Association of Anatomists   245(8):874-80 Full text @ Dev. Dyn.
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Condition:
Anatomical Terms:
Stage Range: 14-19 somites to Prim-5
PHENOTYPE:
Fish:
Condition:
Observed In:
Stage Range: 14-19 somites to Prim-5

Fig. 3

Analysis of gene expression in ntla mutant embryos. A-J: Wild-type, ntla-/-, and ntlacs/cs embryos were placed at 17°C at shield stage, then incubated at 29°C the next morning (when the embryos were at bud stage) and raised to the 14-somite stage. Whereas ntla-/- embryos had essentially no expression of the presomitic genes tbx16 and tbx6l or the notochordal gene col9a2, ntlacs/cs, embryos had strong expression of all three genes. All these embryos were hybridized with the indicated probe at the same time and for the same length of time. K-P: In contrast, when ntlacs/cs embryos were kept continuously at 17°C, expression of all three genes was considerably diminished. Arrows show accumulation of col9a2 in the posterior of ntlacs/cs embryos.

Gene Expression Details
Gene Antibody Fish Conditions Stage Qualifier Anatomy Assay
col9a2 WT cold exposure Prim-5 notochord ISH
tbxtab195/b195 cold exposure Prim-5 Not Detected notochord ISH
tbxtaw181/w181 cold exposure Prim-5 notochord ISH
tbx16 WT cold exposure 14-19 somites segmental plate ISH
tbxtab195/b195 cold exposure 14-19 somites segmental plate ISH
tbxtaw181/w181 cold exposure 14-19 somites segmental plate ISH
Antibody Labeling Details No data available
Phenotype Details
Fish Conditions Stage Phenotype
tbxtab195/b195 cold exposure 14-19 somites segmental plate tbx16 expression decreased amount, abnormal
Prim-5 notochord col9a2 expression absent, abnormal
tbxtaw181/w181 cold exposure 14-19 somites segmental plate tbx16 expression decreased amount, abnormal
Prim-5 notochord col9a2 expression decreased amount, abnormal
