ZFIN ID: ZDB-FIG-130807-1
Shin et al., 2012 - Intrinsic and extrinsic modifiers of the regulative capacity of the developing liver. Mechanisms of Development   128(11-12):525-535 Full text @ Mech. Dev.
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Condition:
Anatomical Terms:
Stage Range: Long-pec to Day 5
PHENOTYPE:
Fish:
Condition:
Observed In:
Stage Range: Long-pec to Day 5

Fig. 4

Sox32 positively regulates liver formation in wnt2bb mutants. (A) Schematic of the dominant-negative Sox32 construct. The transcriptional repressor domain of Drosophila Engrailed was fused to the HMG box (gray box) of Sox32. (B-E) mRNA injections into Tg(sox17:GFP) embryos reveal that dnSox32 blocks Sox32 function. Injections of sox32 mRNA enhanced GFP expression driven by the sox17 promoter; injections of dnsox32 mRNA reduced it. Co-injections of sox32 and dnsox32 mRNA blocked GFP induction by Sox32. Dorsal views, anterior up. (F-H) Hepatic sox17 expression was almost absent (G, 60%) or greatly reduced (H, 40%) in Tg(hs:dnsox32) embryos heat-shocked at 26 hpf (n = 10). Dorsal views, anterior to the left. (I-L) Tg(hs:dnsox32);wnt2bb-/- embryos were heat-shocked at 26 hpf, and examined at 5.5 dpf. The liver (arrows) formed in all Tg(hs:dnsox32), but failed to form in most Tg(hs:dnsox32);wnt2bb-/- embryos (L, 22 out of 25). Side views, anterior up. Scale bars, 100 ┬Ám.

Gene Expression Details
Gene Antibody Fish Conditions Stage Qualifier Anatomy Assay
DsRed gz15Tg standard conditions Day 5 liver IFL
gz15Tg; s921Tg heat shock Day 5 liver IFL
wnt2bbs403/s403; gz15Tg standard conditions Day 5 liver IFL
wnt2bbs403/s403; gz15Tg; s921Tg heat shock Day 5 Not Detected liver IFL
EGFP gz15Tg standard conditions Day 5 exocrine pancreas IFL
gz15Tg; s921Tg heat shock Day 5 exocrine pancreas IFL
wnt2bbs403/s403; gz15Tg standard conditions Day 5 exocrine pancreas IFL
wnt2bbs403/s403; gz15Tg; s921Tg heat shock Day 5 exocrine pancreas IFL
sox17 WT standard conditions Long-pec liver ISH
s921Tg heat shock Long-pec liver ISH
Antibody Labeling Details No data available
Phenotype Details
Fish Conditions Stage Phenotype
gz15Tg; s921Tg heat shock Day 5 liver present, normal
Day 5 pancreas present, normal
s921Tg heat shock Long-pec liver absent, abnormal
Long-pec liver decreased size, abnormal
Long-pec liver development disrupted, abnormal
wnt2bbs403/s403; gz15Tg standard conditions Day 5 liver present, normal
Day 5 pancreas present, normal
wnt2bbs403/s403; gz15Tg; s921Tg heat shock Day 5 liver absent, abnormal
Day 5 liver development disrupted, abnormal
Day 5 pancreas present, normal
