ZFIN ID: ZDB-FIG-090511-6
Hill et al., 2009 - Potential roles of arnt2 in zebrafish larval development. Zebrafish   6(1):79-91 Full text @ Zebrafish
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Gene:
Fish:
Anatomical Terms:
Stage: Protruding-mouth

Fig. 6 mRNA Expression of the Arnt2 dimerization partner, Sim1, is reduced in the hypothalamus and ventral thalamus of arnt2-/- larvae at 72 hpf. ISH of sim1 in a cross section of the brain taken through the ventral thalamus and hypothalamus of a representative WT larva and arnt2-/- larva at 72 hpf shows reduced expression in the arnt2-/- mutant (compare right top and right bottom). In the left panel, black arrows indicate the plane at which the cross section (shown in the right panel) was taken. Eyes of the representative WT larva and arnt2-/- larva were removed after euthanasia (left top and left bottom) so that the pattern of sim1 staining in the whole-mount brain could be seen in lateral view. vt, ventral thalamus; h, hypothalamus.

Gene Expression Details
Gene Antibody Fish Conditions Stage Qualifier Anatomy Assay
sim1a WT standard conditions Protruding-mouth hypothalamus ISH
Protruding-mouth ventral thalamus ISH
arnt2hi1715Tg/hi1715Tg standard conditions Protruding-mouth hypothalamus ISH
Protruding-mouth ventral thalamus ISH
Protruding-mouth Not Detected ventral thalamus ventral region ISH
Antibody Labeling Details No data available
Phenotype Details No data available
