ZFIN ID: ZDB-FIG-090401-46
Toro et al., 2009 - Identification of differentially expressed genes in the zebrafish hypothalamic-pituitary axis. Gene Expression Patterns   9(4):200-208 Full text @ Gene Expr. Patterns
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes: adm2a, hsd3b7, oacyl, pcsk1nl, scg3 (all 6) expand
Fish: WT
Anatomical Terms: adenohypophysis, pars anterior, pars intermedia
Stage: Protruding-mouth

Fig. 1 Genes expressed in the adenohypophysis. (A) scg3, (B) slc16a9a, (C) hsd3b7, (D) adm2, (E) uo:ion002 and (F) uo:ion003 are expressed (blue) in the adenohypophysis that is delimited by pomc expression (red). scg3 (A) and slc16a9a (B) are expressed in the rostral pars distalis (RPD). (C) hsd3b7 is expressed in the entire gland. (D) The EST adm2 is expressed in the proximal pars distalis (PPD) and pars intermedia (PI). (E) The novel gene uo:ion002 is expressed in the PI. (F) The novel gene uo:ion003 is expressed in the rostral pars distalis (RPD). Ventral views of adenohypophysis at 72 h, anterior to the top; scale bar 50 μm.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
adm2a WT standard conditions Protruding-mouth adenohypophysis ISH
Protruding-mouth pars anterior ISH
Protruding-mouth pars intermedia ISH
hsd3b7 WT standard conditions Protruding-mouth adenohypophysis ISH
oacyl WT standard conditions Protruding-mouth adenohypophysis ISH
Protruding-mouth pars intermedia ISH
pcsk1nl WT standard conditions Protruding-mouth adenohypophysis ISH
Protruding-mouth pars anterior ISH
scg3 WT standard conditions Protruding-mouth adenohypophysis ISH
Protruding-mouth pars anterior ISH
slc16a9a WT standard conditions Protruding-mouth adenohypophysis ISH
Protruding-mouth pars anterior ISH
Antibody Labeling Details No data available
Phenotype Details No data available
Acknowledgments:
ZFIN wishes to thank the journal Gene Expression Patterns for permission to reproduce figures from this article. Please note that this material may be protected by copyright.

Reprinted from Gene Expression Patterns, 9(4), Toro, S., Wegner, J., Muller, M., Westerfield, M., and Varga, Z.M., Identification of differentially expressed genes in the zebrafish hypothalamic-pituitary axis, 200-208, Copyright (2009) with permission from Elsevier. Full text @ Gene Expr. Patterns
