ZFIN ID: ZDB-IMAGE-090401-45
Figures for Toro et al., 2009

Genes: adm2a, hsd3b7, oacyl, pcsk1nl, scg3 (all 6) expand

Figure Caption/Comments:

Fig. 1 Genes expressed in the adenohypophysis. (A) scg3, (B) slc16a9a, (C) hsd3b7, (D) adm2, (E) uo:ion002 and (F) uo:ion003 are expressed (blue) in the adenohypophysis that is delimited by pomc expression (red). scg3 (A) and slc16a9a (B) are expressed in the rostral pars distalis (RPD). (C) hsd3b7 is expressed in the entire gland. (D) The EST adm2 is expressed in the proximal pars distalis (PPD) and pars intermedia (PI). (E) The novel gene uo:ion002 is expressed in the PI. (F) The novel gene uo:ion003 is expressed in the rostral pars distalis (RPD). Ventral views of adenohypophysis at 72 h, anterior to the top; scale bar 50 μm.

Figure Data:
