FIGURE

Fig. 2

ID
ZDB-FIG-080411-46
Publication
Eaton et al., 2008 - Ontogeny of vasotocin-expressing cells in zebrafish: Selective requirement for the transcriptional regulators orthopedia and single-minded 1 in the preoptic area
Other Figures
All Figure Page
Back to All Figure Page
Fig. 2

A-E: The avt-expressing cells of the ventral hypothalamus are located at the edges of the shha and titf1a expression domains. Coexpression of avt, titf1a, and shha mRNA was determined by double-label in situ hybridization (ISH). Lateral views, dorsal is up and anterior to the left. The age of the embryos is indicated on each panel in hours postfertilization (hpf). A,C,D,E,G,H: The eyes have been removed. The identity and color of the probes are indicated on each panel. A,C,E,G: Images are merged composites of brightfield and epifluorescence images. The avt-expressing cell groups in the ventral hypothalamus are indicated by black arrows, whereas the avt cell group in the dorsal preoptic area is indicated with a black arrowhead. Scale bars = 100 μm.

Expression Data
Genes:
Fish:
Anatomical Terms:
Stage Range: Prim-25 to Long-pec

Expression Detail
Antibody Labeling
Phenotype Data

Phenotype Detail
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Dev. Dyn.
