Fig. 1

Etv2 function is necessary for neutropoiesis in the ALPM and is sufficient to initiate mpx expression. (A–K) Anterior but not posterior mpx expression is greatly reduced or absent in etv2^y11mutants, as analyzed by in situ hybridization. (A and B) mpx expression is slightly reduced in the ICM region of etv2^y11 mutants (B) as compared to their wild-type siblings (A) at the 20 somite stage. (C) Number of mpx-expressing cells at various stages in the anterior and posterior lateral plate mesoderm of wild type and etv2^y11 mutant embryos. The cells were counted in 30 wt and 23 etv2^y11 mutant embryos at the 20-somite stage, 16 wt and 16 mutant embryos at 24 hpf and 10 wt and 9 mutant embryos at 30 hpf. Error bars correspond to±standard deviation. Asterisks denote significant differences (p<0.05) calculated by Studentós T-Test. (D and E) mpx expression is strongly reduced at 24 hpf in the ALPM of etv2^y11 mutants (E) compared to wild type siblings (D). (F and G) mpx expression has only a minor reduction in the ICM region of etv2^y11 mutants (G) compared to their wild-type siblings (F). (H–K) mpx expression is reduced at 30 hpf in the anterior (I) and posterior (K) of etv2^y11 mutants compared to wild type siblings (H and J). (L and M) gata1 expression is not significantly affected in etv2^y11 mutants (M) as compared to wild-type siblings at 24 hpf (L). (N and O) cebpa expression at 24 hpf is strongly reduced in 100% of etv2^y11 mutants (O, n=11) while it is strongly expressed in 100% of wild-type siblings (N, n=11). (P, Q) lyz expression is strongly reduced in 100% of etv2^y11 mutants (Q, n=14) compared to 100% of wild-type siblings with normal lyz expression (P, n=15). (R–U) Etv2 DNA overexpression results in ectopic mpx expression as analyzed by in situ hybridization (R and S) and mpx:GFP live fluorescence (T and U) at the 20-somite stage (65% of etv2-injected embryos with increased or ectopic mpx:GFP, n=115 as opposed to 0% controls, n=39). Note that mpx:GFP exhibits non-specific GFP fluorescence in the neural tube. All embryos are positioned with the anterior to the left and dorsal side up.

Figure Data

Expression / Labeling details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 393(1), Glenn, N.O., Schumacher, J.A., Kim, H.J., Zhao, E.J., Skerniskyte, J., Sumanas, S., Distinct regulation of the anterior and posterior myeloperoxidase expression by Etv2 and Gata1 during primitive Granulopoiesis in zebrafish, 149-59, Copyright (2014) with permission from Elsevier. Full text @ Dev. Biol.
