ZFIN Image: Warga et al., 2013, Fig. 2


Figure Caption

Fig. 2 spt mutants possess more nephric precursors, but have fewer endothelial and hematopoietic precursors. (A–G) Expression in the trunk at 14.5 h of: (A) pax2a and (B) jag2, in nephric cells; (C) fli1a and (D) cdh5, in endothelial cells; and (E) spi1, in white, (F) gata1, in red, and (G) tal1, in all blood cells (arrow designates a single cell). (H, I) Expression in the head at 14.5 h of: (H) fli1a, in endothelial cells; and (I) spi1, in macrophages. (J, K) Quantification of intermediate mesoderm precursors for: (J) trunk, and (K) head. Graphs show the average number of cells per marker including standard error; 9 embryos for each category were counted. Embryos are shown from a (A–G) posterior view, or (H, I) anterior view with dorsal to the top.

Figure Data

Expression / Labeling details

Phenotype details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 383(1), Warga, R.M., Mueller, R.L., Ho, R.K., and Kane, D.A., Zebrafish Tbx16 regulates intermediate mesoderm cell fate by attenuating Fgf activity, 75-89, Copyright (2013) with permission from Elsevier. Full text @ Dev. Biol.
