Figure Caption

Fig. 4

Fig. 4. Ctr9, Cdc73, and Paf1 are required for AV boundary specification. (A–D) Cardiac expression of vmhc in 48 hpf embryos. In wild type (A), ctr9LA961 mutant (B), cdc73 morphant (C), and paf1 morphant (D) embryos, vmhc expression is detected primarily in the ventricle. (E–H) Cardiac expression of amhc in 48 hpf embryos. In wild type (E), ctr9LA961 mutant (F), cdc73 morphant (G), and paf1 morphant (H) embryos, amhc expression is detected primarily in the atrium. (I–L) Cardiac expression of bmp4 in 48 hpf embryos. In wild type embryos (I), bmp4 expression is detected in the myocardium of the ventricle, sinus venosus, and AV boundary (arrow). Ctr9LA961 mutant (J), cdc73 morphant (K), and paf1 morphant (L) embryos display ventricular expression of bmp4, but have no discernable AV boundary expression. (M–P) Cardiac expression of tbx2b in 48 hpf embryos. In wild type embryos, tbx2b is expressed by the myocardium of the AV boundary (arrow, M). Ctr9LA961 mutant (N), cdc73 morphant (O), and paf1 morphant (P) embryos instead aberrantly express tbx2b throughout the heart. (Q–T) Cardiac expression of notch1b in 48 hpf embryos. Notch1b is expressed by the AV boundary endocardium in wild type embryos (arrow, Q), but is not expressed in the hearts of ctr9LA961 mutants (R), cdc73 morphants (S), and paf1 morphants (T).

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 353(1), Langenbacher, A.D., Nguyen, C.T., Cavanaugh, A.M., Huang, J., Lu, F., and Chen, J.N., The PAF1 complex differentially regulates cardiomyocyte specification, 19-28, Copyright (2011) with permission from Elsevier. Full text @ Dev. Biol.
