Figure Caption
Fig. S3 Inhibition of either the Fgf or RA signal did not perturb the others signaling gradient in cdx1a/4 morphant embryos. Expression of fgf3 (A) and fgf8 (B) in DEAB-treated cdx1a/4 morphants, and expression of raldh2 (C) and cyp26a1 (D) in SU5402-treated cdx1a/4 morphants, at 13 hpf. Scale bar in A: 100 μm for A-D.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Development
