Fig. 2

Psoriasis lesional skin has lower protein levels of GPER1 and the activated form of CREB.

Representative images of biopsy sections from healthy and psoriasis patients immunostained with anti-GPER1 (a) and anti-pCREB (b). Sections were examined under a Leica microscope DMC6200 equipped with a Leica DFC 280 digital camera. No staining was observed when primary antibodies were omitted. Magnification at 20X and 40X (scale bar 100 µm and 50 µm, respectively). CL Cornified layer, SL Spinous layer, D dermis.
