Fig. 1.

Gross phenotype of cilia-related mutants and wild-type (WT) zebrafish across time. Lateral views of WT and mutant animals at 2 days post fertilization (dpf), 5 dpf, 3 weeks post fertilization (wpf) and >3 months post fertilization (mpf; adult). The penetrance of the imaged phenotype [curled-down tail (CDT) and/or scoliosis for most, a decreased head-trunk-angled defect (HTA) for mks1 and b9d2, and small size for tmem216] in −/− animals is indicated in the bottom right of each panel (P, observed/total number of −/− identified). At 3 wpf and in adults, we indicate the Mendelian inheritance (MI) in the bottom left of each panel. MI was calculated as % of the number of observed −/− divided by the expected number of −/− (1/3 of the sum of observed +/+ and +/−). Scale bars: 1000 μm.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	b9d2^uab17/uab17 (AB) cc2d2a^uab16/uab16 (AB) cep290^uab18/uab18 (AB) ift88^tz288/tz288 ift172^uab11/uab11 (AB) mks1^uab12/uab12 (AB) nphp1^uab20/uab20 (AB) nphp4^uab21/uab21 (AB) rpgrip1l^uab15/uab15 (AB) tctn1^uab19/uab19 (AB) tmem67^uab14/uab14 (AB) tmem216^uab13/uab13 (AB) (all 12)
Observed In:	head post-vent region trunk vertebral column whole organism
Stage Range:	Long-pec to Adult
