FIGURE

Fig. 1

ID

ZDB-FIG-180724-22

Publication

Schredelseker et al., 2018 - Bsx controls pineal complex development

Other Figures

All Figure Page

Back to All Figure Page

Fig. 1

bsx expression during zebrafish embryonic development. (A-I?) bsx expression visualized by WISH. (A-I) Lateral views of head region of zebrafish embryos, and (A?-I?) dorsal views of the PC of the same embryos. Developmental stages (S, somite stage) and orientations (A, anterior; D, dorsal; L, left; P, posterior; R, right; V, ventral; dashed line indicates the midline) are indicated. HB, hindbrain; Hyp, hypothalamus (c, caudal; r, rostral; v, ventral); pTh, prethalamus; Sep, septal region; Tec, midbrain tectum; Tel, telencephalon. Scale bar: 100?µm.

Expression Data

Gene:	bsx
Fish:	AB/TL
Anatomical Terms:	diencephalon ventral region epiphysis hypothalamus hypothalamus anterior region hypothalamus posterior region hypothalamus ventral region parapineal organ pineal complex ventral telencephalon ventral thalamus
Stage Range:	10-13 somites to Day 5

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Development
