Fig. 3-S1

Regulation of wu:fc23c0 by Yap1 and Wwtr1.

(A,B) wu:fc23c0 is strongly expressed throughout the notochord of sibling embryos (A) but not expressed in the posterior notochord of yap1;wwtr1 double mutant embryos. (C–E) Transgenic embryos obtained from an outcross of hemizygous HS:DN-yap or HS:CA-yap adults were heat shocked at the 4-somite stage and then grown to 18 somites. The genotype of the embryos was determined by PCR after the in situ hybridization to be either transgenic or non-transgenic control. Expression of DN-yap decreased posterior notochord wu:fc23c0 expression (D, n = 10) whereas CA-yap did not appear to alter wu:fc23c0 expression (E, n = 8) relative to control non-transgenic embryos (C).

Expression Data

Gene:	wu:fc23c09
Fish:	WT zf621Tg zf622Tg yap1^bns19/bns19; wwtr1^bns35/bns35
Condition:	heat shock
Anatomical Terms:	notochord notochord posterior region
Stage:	14-19 somites

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	zf621Tg yap1^bns19/bns19; wwtr1^bns35/bns35
Condition:	heat shock
Observed In:	notochord posterior region
Stage:	14-19 somites

Phenotype Detail
