ZFIN ID: ZDB-FIG-171205-29
Fig. 4 S4
The prostaglandin receptor transcripts ptger2a and ptger4a are expressed in the pronephros during development and co-localize with the nephron.
WT embryos from the 12 ss through 26 ss were stained for (A) ptger2a or (B) ptger4a transcript expression (purple) and the somites (red) using WISH. The ptger2a and ptger4a expression domains are framed in black boxes. WT embryos at the 14 ss and 18 ss were co-stained for (C) ptger2a and cdh17 (D) and ptger4a and cdh17, where transcripts encoding the latter mark the entire nephron. Asterisks demarcate co-localization between markers. Black bars indicate receptor gene expression domain. Red scale bar, 70 µm.
Antibody Labeling Details No data available
Phenotype Details No data available
ZFIN wishes to thank the journal eLIFE for permission to reproduce figures from this article.
Please note that this material may be protected by copyright.
Full text @ Elife
