ZFIN ID: ZDB-FIG-170531-5
Miyake et al., 2017 - Brorin is required for neurogenesis, gliogenesis, and commissural axon guidance in the zebrafish forebrain. PLoS One   12:e0176036 Full text @ PLoS One
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Gene:
Antibody:
Fish:
Knockdown Reagent:
Anatomical Term:
Stage: Prim-5
PHENOTYPE:
Fish:
Knockdown Reagent:
Observed In:
Stage: Prim-5

Fig. 4

pSmad distribution and expression of the Wnt target gene in brorin morphants.

(A, B) Pattern of pSmad expression in wild-type embryos (A) and brorin morphants (B) at 24 hpf. (C, D) Expression of axin2 in wild-type embryos (C) and brorin morphants (D) at 24 hpf. Lateral view with the anterior to the left.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
axin2 WT standard conditions Prim-5 brain dorsal region ISH
WT + MO1-vwc2 standard conditions Prim-5 brain dorsal region ISH
Antibody Labeling Details
Antibody Assay Fish Conditions Stage Anatomy
Ab1-smad IHC WT standard conditions Prim-5 brain dorsal region
IHC WT + MO1-vwc2 standard conditions Prim-5 brain dorsal region
Phenotype Details
Fish Conditions Stage Phenotype
WT + MO1-vwc2 standard conditions Prim-5 brain BMP signaling pathway increased occurrence, abnormal
Prim-5 brain dorsal region ab1-smad labeling increased amount, abnormal
Prim-5 brain Wnt signaling pathway occurrence, normal
