Fig. 1

Nemaline bodies form in skeletal muscle in Tg(ACTA1 ^D286G-eGFP)_high zebrafish. Nemaline bodies were detected in a skeletal muscle (arrowheads) and pectoral fins (arrow) (i and ii overlaid with brightfield), b heart (arrowheads) (i and ii overlaid with brightfield), c facial muscles (arrowheads) (i and ii overlaid with brightfield) and d ocular muscles (arrowheads; i and overlaid with ii brightfield)

Expression Data

Gene:	EGFP
Fish:	mnu3Tg; mnu5Tg
Anatomical Terms:	cardiac muscle cardiac muscle cellular anatomical structure extraocular musculature extraocular musculature cellular anatomical structure pectoral fin pectoral fin cellular anatomical structure pharyngeal musculature pharyngeal musculature cellular anatomical structure skeletal muscle skeletal muscle cellular anatomical structure
Stage Range:	Long-pec to Protruding-mouth

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	mnu3Tg; mnu5Tg
Observed In:	skeletal muscle cellular anatomical structure
Stage Range:	Long-pec to Protruding-mouth

Phenotype Detail
