Fig. 13

pcdh19, pcdh17, and cdh6 expression in the medulla oblongata. Top panels show low magnifications of adjacent sections from a level shown in Fig. 1. B–D: Higher magnified views of the dorsal halves, while E–G are ventral portions of their respective images in the top panels. H–N: From sections 200–250 µm posterior to A, with H–K showing magnified views of the dorsal medulla, while L–N showing the ventral medulla. Asterisks in D and E indicate artificial cracks in the sections. See list for abbreviations. Scale bar = 200 µm for the top panels, 50 µm for the remaining panels (E–K have the same magnification).

Expression Data

Genes:	cdh6 pcdh17 pcdh19
Fish:	WT
Anatomical Terms:	medial funicular nucleus medulla oblongata motor nucleus of vagal nerve reticular formation sensory root of facial nerve vagal lobe ventral funiculus (all 6)
Stage:	Adult
