ZFIN ID: ZDB-FIG-150423-35
Filipek-Górniok et al., 2015 - The Ndst Gene Family in Zebrafish: Role of Ndst1b in Pharyngeal Arch Formation. PLoS One   10:e0119040 Full text @ PLoS One
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Anatomical Terms:
Stage Range: Prim-5 to Long-pec

Fig. 4

Expression of zebrafish ndst genes at 24, 38 and 50 hpf.

Lateral and dorsal view of the embryos, or head region of the embryo. Embryonic expression patterns are shown for ndst1a: A-E; ndst1b: F-J; ndst2a: K-O; ndst2b: P-T; ndst3: U-Y. Abbreviations used: h, hindbrain; icm, intermediate cell mass (blood islands); op, olfactory placode and olfactory bulb; r, rhombomeres; s:, somites; sc, spinal cord; t, tectum; te, telencephalon.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
ndst1a WT standard conditions Prim-5 optic tectum ISH
Prim-25 optic tectum ISH
Long-pec optic tectum ISH
ndst1b WT standard conditions Prim-5 myotome ISH
Prim-5 rhombomere ISH
Prim-25 hindbrain ISH
Prim-25 intermediate cell mass of mesoderm ISH
Long-pec hindbrain ISH
ndst2a WT standard conditions Prim-5 head ISH
Prim-25 head ISH
Long-pec head ISH
ndst2b WT standard conditions Prim-5 optic tectum ISH
Prim-25 brain ISH
Long-pec brain ISH
Long-pec rhombomere ISH
ndst3 WT standard conditions Prim-5 brain ISH
Prim-5 hindbrain ISH
Prim-5 olfactory placode ISH
Prim-5 optic tectum ISH
Prim-5 spinal cord ISH
Prim-25 brain ISH
Prim-25 spinal cord ISH
Long-pec brain ISH
Long-pec rhombomere ISH
Long-pec spinal cord ISH
Antibody Labeling Details No data available
Phenotype Details No data available
