FIGURE

Fig. 6

ID

ZDB-FIG-150218-7

Publication

Miyake et al., 2014 - Fgf16 Is Required for Specification of GABAergic Neurons and Oligodendrocytes in the Zebrafish Forebrain

Other Figures

All Figure Page

Back to All Figure Page

Fig. 6

Effects of fgf16 on the development of glutamatergic neurons, GABAergic interneurons, and oligodendrocyte progenitor cells.

(A–D) The expression of ngn1 (A, B) and isl1 (C, D) in wild-type embryos (A, C) and fgf16 morphants (B, D) at 24 hpf. Lateral views with anterior to the left and dorsal to the top. (E–J) The expression of gad1 (E, F), olig2 (G, H), and slc17a6a (I, J) in wild-type embryos (E, G, I) and fgf16 morphants (F, H, J) at 28 hpf. Lateral views with anterior to the left and dorsal to the top.

Expression Data

Genes:	gad1b isl1a neurog1 olig2 slc17a6a
Fish:	WT WT + MO1-fgf16
Knockdown Reagent:	MO1-fgf16
Anatomical Terms:	diencephalon diencephalon neuron dorsal telencephalon dorsal thalamus epiphysis neuron GABAergic neuron glutamatergic neuron nucleus of the tract of the postoptic commissure oligodendrocyte telencephalon neuron ventral telencephalon ventral thalamus
Stage:	Prim-5

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	WT + MO1-fgf16
Knockdown Reagent:	MO1-fgf16
Observed In:	diencephalon neuron differentiation forebrain GABAergic neuron GABAergic neuron differentiation glutamatergic neuron oligodendrocyte oligodendrocyte differentiation ventral telencephalon neuron differentiation
Stage:	Prim-5

Phenotype Detail
