Fig. 7

Effects of fgf16 on the differentiation of GABAergic interneurons and oligodendrocytes.

(A, B) Dorsal views of wild-type embryos (A) and fgf16 morphants (B), labeled to show GABA immunoreactivity at 3 dpf. (C, D) The expression of plp in wild-type embryos (C) and fgf16 morphants (D) at 4.5 dpf. Lateral views with anterior to the left and dorsal to the top.

Expression Data

Gene:	plp1a
Antibody:	Ab1-GABA
Fish:	WT WT + MO1-fgf16
Knockdown Reagent:	MO1-fgf16
Anatomical Terms:	forebrain GABAergic neuron forebrain oligodendrocyte hindbrain oligodendrocyte
Stage Range:	Protruding-mouth to Day 4

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	WT + MO1-fgf16
Knockdown Reagent:	MO1-fgf16
Observed In:	forebrain GABAergic neuron GABAergic neuron differentiation hindbrain oligodendrocyte oligodendrocyte differentiation
Stage Range:	Protruding-mouth to Day 4

Phenotype Detail
