Fig. 3

A-N Slitrk expression at 48 hr postfertilization (hpf) is observed in the developing nervous system. In situ hybridization performed on whole-mount zebrafish embryos at 48 hpf demonstrates differential expression patterns throughout the developing brain of seven different slitrks. A dorsal view of the head (left) and lateral view of the whole embryo (right) are provided for each slitrk gene. M, midbrain; NE, neuroepithelium; OV, otic vesicle; PG, pineal gland; RH, rhombomeres of the hindbrain. Scale bars, 50 μm.

Expression Data

Genes:	slitrk1 slitrk2 slitrk3a slitrk3b slitrk4 slitrk5a slitrk6 (all 7)
Fish:	WT
Anatomical Terms:	diencephalon epiphysis head midbrain neuroepithelial cell otic vesicle rhombomere telencephalon (all 8)
Stage:	Long-pec
