Fig. S5

kremen1 Is Present in the Endoderm at 24 hpf, and Its Roles in Early Endoderm and Liver Development. related to Figure 4
(A) kremen1 (krm1) is ubiquitously expressed at 24 hpf.
(B and C) Endodermal cells are collected by sorting out GFP positive cells from Tg(sox17:GFP) transgenic embryos.
(D) Presence of kremen1 in the endoderm is confirmed by RT-PCR using sorted endodermal cells. Transcriptions of foxa3 and otx2 are applied as positive and negative controls, respectively.
(E and F) In contrast to the wild-type (E), injection of kremen1 mRNA results in slightly increased number of endodermal cells and mildly expanded endoderm at the 14-somite stage (F) as observed under the Tg(sox17:GFP) background.
(G and H) Injection of kremen1MO leads to reduced number of endodermal cells (G), which is rescued by the co-injection of kremen1 mRNA (H).
(I and J) Expressions of Kremen1-GFP at 26 hpf caused by heat shock of Tg(hsp70l: kremen1-GFP) transgenic embryos at 18 hpf.
(K and L) In contrast to the Kremen1-GFP negative embryos (K), liver development is aberrant in the Kremen1-GFP positive embryos at 102 hpf (L).

Expression Data
Genes:
Fish:
Anatomical Terms:
Stage: Prim-5

Expression Detail
Antibody Labeling
Phenotype Data
Fish:
Condition:
Knockdown Reagent:
Observed In:
Stage Range: 14-19 somites to Day 4

Phenotype Detail
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Cell, 24(5), Lu, H., Ma, J., Yang, Y., Shi, W., and Luo, L., EpCAM Is an Endoderm-Specific Wnt Derepressor that Licenses Hepatic Development, 543-553, Copyright (2013) with permission from Elsevier. Full text @ Dev. Cell
