Fig. 5

Co-misexpressing foxi1 and gata3 in tfap2a/c morphants. A-D, Expression of pax2a in the otic/epibranchial placodes at 12 hpf. E–H, Expression of fgf24 in the otic placode at 12 hpf. I–L, Expression of dlx3b in placodal tissues at 12 hpf. M-P, otic vesicle at 24 hpf. Non-transgenic controls and hs:foxi1-hs:gata3 double transgenic embryos are marked across the top, and the lower half of each panel shows tfap2a/c morphants and double transgenic tfap2a/c morphants. Activation of the transgenes at 7 hpf partially rescued otic development in tfap2a/c morphants. Images show dorsal views with anterior to the top (A-L) or lateral views with anterior to the left (M-P).

Expression Data

Genes:	dlx3b fgf24 pax2a
Fish:	WT x19Tg; x25Tg WT + MO2-tfap2c + MO4-tfap2a x19Tg; x25Tg + MO2-tfap2c + MO4-tfap2a
Condition:	heat shock
Knockdown Reagents:	MO2-tfap2c MO4-tfap2a
Anatomical Terms:	epibranchial field neurogenic field otic placode
Stage:	5-9 somites

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	x19Tg; x25Tg WT + MO2-tfap2c + MO4-tfap2a
Condition:	heat shock
Knockdown Reagents:	MO2-tfap2c MO4-tfap2a
Observed In:	otic placode otic vesicle
Stage Range:	5-9 somites to Prim-5

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 373(1), Bhat, N., Kwon, H.J., and Riley, B.B., A gene network that coordinates preplacodal competence and neural crest specification in zebrafish, 107-117, Copyright (2013) with permission from Elsevier. Full text @ Dev. Biol.
