Fig. 3
bcl2l expression in the zebrafish thyroid is not controlled bypax8. Lateral views with anterior to the left. Stage is indicated at bottom left, experimental morpholino at bottom right and marker at top right. (A) and (B) bcl2l expression in control (A) and in pax8 morphant embryos (B) is similar. (A′, B′) Morphology of the otic vesicles in control (A′) and pax8 morphant embryo (B′) at 24 hpf showing the efficiency of the injected MO (Mackereth et al., 2005). (C) and (D) hhex expression in the thyroid primordium of control (C) and pax8 morphant embryo (D) is similar. Arrow indicates the thyroid primordium. |
Genes: | |
---|---|
Fish: | |
Knockdown Reagent: | |
Anatomical Term: | |
Stage: | Long-pec |
Fish: | |
---|---|
Knockdown Reagent: | |
Observed In: | |
Stage: | Prim-5 |
Reprinted from Developmental Biology, 366(2), Porreca, I., De Felice, E., Fagman, H., Di Lauro, R., and Sordino, P., Zebrafish bcl2l is a survival factor in thyroid development, 142-152, Copyright (2012) with permission from Elsevier. Full text @ Dev. Biol.
