FIGURE

Fig. 3

ID

ZDB-FIG-120508-46

Publication

Zhang et al., 2012 - The Expression of irx7 in the Inner Nuclear Layer of Zebrafish Retina Is Essential for a Proper Retinal Development and Lamination

Other Figures

All Figure Page

Back to All Figure Page

Fig. 3

The phenotypes of irx7SMO and irx7MO2 morphants at 72 hpf.

Phenotypic analysis of the optimized irx7SMO (A–E) and irx7MO2 (F–J) injection experiments. (A) The lateral view of an uninjected control embryo for irx7SMO injection experiments. (B) An embryo injected with 10 ng of Control MO. (C–E) Three phenotypic categories of the morphants after injected with 10 ng of irx7SMO. The percentage of embryos that had mild (C), intermediate (D) and severe (E) phenotypes was 13.52% (N = 106), 69.81% (N = 444) and 16.67% (N = 86) respectively. (F) The lateral view of an uninjected control embryo for irx7MO2 injection experiments. (G) An embryo injected with 3 ng of irx7MO2-6 bms. (H–J) Three phenotypic categories of morphants after injected with 3 ng of irx7MO2. The percentage of embryos that had mild (H), intermediate (I), and severe (J) phenotypes were 13.28% (N = 38), 73.78% (N = 211) and 12.94% (N = 37) respectively. Scale bar = 200 μm.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	AB + MO2-irx7 AB + MO3-irx7
Knockdown Reagents:	MO2-irx7 MO3-irx7
Observed In:	eye whole organism
Stage:	Protruding-mouth

Phenotype Detail
