ZFIN ID: ZDB-FIG-100616-71
Takano et al., 2010 - Expression of strawberry notch family genes during zebrafish embryogenesis. Developmental dynamics : an official publication of the American Association of Anatomists   239(6):1789-1796 Full text @ Dev. Dyn.
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Anatomical Terms:
Stage Range: Prim-5 to Protruding-mouth

Fig. 6 Serial sections of the whole-mount in situ hybridization specimens. A-L: The coronal sections of 24 hours postfertilization (hpf) embryos hybridized to sbno1 (A-C), sbno2a (D-F), delta A (G-I), or HuC (J-L) probes. A,D,G,J: The section 20 to 40 micrometers in depth from the anterior top of the embryos. B,E,H,K: The sections at the anterior midbrain level. C,F,I,L: The sections at the hindbrain level. M,N: The coronal sections of 3 days postfertilization (dpf) larvae at midbrain level hybridized to sbno1 (M) or sbno2a (N) probes. Whole-mount in situ hybridization specimens were embedded in the plastic resin and cut at 10-micrometer thickness. The sections were counterstained by 4′,6-diamidine-2-phenylidole-dihydrochloride (DAPI), and the bright field image showing in situ staining (yellow) and fluorescent image showing DAPI staining (blue) of the same sections were merged. Scale bars = 0.1 mm.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
dla AB standard conditions Prim-5 midbrain posterior region ISH
elavl3 AB standard conditions Prim-5 midbrain posterior region ISH
sbno1 AB standard conditions Prim-5 neural tube dorsal side ISH
Protruding-mouth retinal ganglion cell layer ISH
Protruding-mouth retinal inner nuclear layer ISH
sbno2a AB standard conditions Prim-5 neural tube dorsal side ISH
Protruding-mouth retinal ganglion cell layer ISH
Protruding-mouth retinal inner nuclear layer ISH
Antibody Labeling Details No data available
Phenotype Details No data available
