FIGURE

Fig. 2

ID

ZDB-FIG-100504-1

Publication

Grinblat et al., 2001 - zic gene expression marks anteroposterior pattern in the presumptive neurectoderm of the zebrafish gastrula

Other Figures

All Figure Page

Back to All Figure Page

Fig. 2

zic gene expression is patterned in the neurectoderm during gastrulation. Staged embryos were stained for opl/zic1, zic2, zic3 (purple), and otx2 RNA (orange in G-I) by using whole-mount in situ hybridization. A-C: Early gastrula (shield) stage embryos, dorsal view, anterior at the top. A: opl/zic1 is not expressed. B: zic2 is expressed in the blastoderm margin, the presumptive mesendoderm, only. C: zic3 expression in the posterior portion of the dorsal ectoderm and in the blastoderm margin. D-F: Mid-gastrula (80% epiboly) stage embryos, dorsal view, anterior at the top. D: opl/zic1 expression restricted to an anterior domain of the neural plate. E: zic2 expression domain includes the anterior opl domain and extends more posteriorly. F: zic3 is expressed in the posterior portion of the neural plate and at the edge of the neural plate anteriorly. G-I: Late gastrula (90% epiboly) stage embryos, dorsal view, anterior at the top. G,H: Expression of opl (G) and zic2 (H), shown in purple, overlap the otx2 (orange) expression domain in the presumptive forebrain. I: anterior portion of zic3 expression overlaps the posterior portion of the otx2 domain. Dots indicate outline of the blastoderm margin. White arrowheads point to the posterior extent of otx2 staining, which corresponds to the future posterior midbrain.

Expression Data

Genes:	otx2b zic1 zic2a zic3
Fish:	WT
Anatomical Terms:	anterior presumptive neural plate forebrain neural plate margin midbrain neural plate posterior presumptive neural plate presumptive ectoderm
Stage Range:	Shield to 90%-epiboly

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
