Fig. 1

Nestin expression in zebrafish embryos.

A–D. Analysis of nestin transcripts by whole-mount in situ hybridization in embryos injected with control MO. A and C, lateral view from left; B, dorsal view, head at top and D, dorsal view, head at left. Scale bar: 200 μm. E. Nucleotide sequence around the translation start site of zebrafish nestin cDNA and corresponding sequence of nestin MO1 and MO2. F. Western blot analysis of nestin:GFP fusion proteins in 30 hpf embryos treated with nestin MO (10 ng) or its 5-mis MO control (10 ng). The proteins were immunoblotted (IB) with a GFP (α-GFP) or actin antibody (α-actin).

Expression Data

Gene:	nes
Fish:	AB
Anatomical Terms:	central nervous system whole organism
Stage Range:	5-9 somites to Prim-5

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
