Fig. 5

lep/ptc2 mutants display Müller glial reactivity and morphological abnormalities in the ILM. Immunohistochemical analysis using glutamine synthetase (GS) antibody, which marks differentiated Müller glia and their endfeet at the ILM, highlights disruptions in the ILM. (A) In sibling retinas, the ILM is tight and continuous (inset). (B) In lep/ptc2 retinas the ILM is discontinuous and Müller glial endfeet do not terminate properly at the ILM (inset). Glial fibrillary acidic protein (GFAP) antibody staining reveals elevated immuno-reactivity in the inner retina, adjacent to the optic nerve of lep/ptc2 (D and arrows in D′) mutant retinas as compared to siblings (C, C′). Approximately 40% of analyzed mutants displayed significant ILM disruptions and elevated GFAP levels.

Expression Data

Gene:	gfap
Antibodies:	Ab1-glul zrf-1
Fish:	WT ptch1^tj222/tj222 (AB)
Anatomical Term:	Muller cell
Stage:	Day 5

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	ptch1^tj222/tj222 (AB)
Observed In:	inner limiting membrane iris Muller cell axon terminus
Stage:	Day 5

Phenotype Detail
