FIGURE

Fig. 1

ID

ZDB-FIG-090511-15

Publication

Willett et al., 1997 - Expression of zebrafish rag genes during early development identifies the thymus

Other Figures

All Figure Page

Back to All Figure Page

Fig. 1

Whole-mount in situ hybridization of rag expression during zebrafish development. (A) Embryos and larvae were harvested at 3- hr intervals and hybridized with either a rag1 sense or antisense probe. Staining with the rag1 antisense probe shows expression in bilaterally symmetric spherical regions posterior to the eye. Top row, original magnification 55x; middle row, original magnification 110x; bottom row, staining with the rag1 sense control (original magnification 110x). (B) rag1 whole-mount in situ hybridization of a 2- week-old fish. (C) rag1 staining of several 1-week-old fish. (D)A 7-day-old fish hybridized to rag2 under the same whole-mount hybridization conditions used for rag1.

Expression Data

Genes:	rag1 rag2
Fish:	WT
Anatomical Term:	thymus
Stage Range:	Protruding-mouth to Days 14-20

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 182(2), Willett, C.E., Zapata, A.G., Hopkins, N.A., and Steiner, L.A., Expression of zebrafish rag genes during early development identifies the thymus, 331-341, Copyright (1997) with permission from Elsevier. Full text @ Dev. Biol.
