Fig. S2

bra Expression is Initiated and Maintained in Mesodermal Precursors of ntl -/- Embryos
(A?F) bra expression at the indicated stages in wildtype siblings and ntl -/- embryos shows proper initiation of bra in the margin and continued expression in the mesodermal precursors of ntl -/- embryos (arrows). Expression of bra is lost in the notochord of ntl -/- embryos (arrowheads). Embryos are shown from a (A, B) dorsal view with the animal pole to the top, (C, D) vegetal view with dorsal to the right, and (E, F) posterior view with dorsal to the top.

Expression Data
Gene:
Fish:
Anatomical Terms:
Stage Range: 50%-epiboly to Bud

Expression Detail
Antibody Labeling
Phenotype Data

Phenotype Detail
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Cell, 15(1), Martin, B.L., and Kimelman, D., Regulation of canonical Wnt signaling by Brachyury is essential for posterior mesoderm formation, 121-133, Copyright (2008) with permission from Elsevier. Full text @ Dev. Cell
