Fig. 3

v0-ATPase a1 Expression in Macrophages and Microglia of the Zebrafish Embryo

(A–C) Side view of the wild-type fish trunk at 1 dpf (day post fertilization). (A) pU1-Gal4-UAS-GFP labels the myeloid lineage in green. (B) atp6v0a1 expression in red (C) Merge.

(D–F) Side view of the wild-type fish head at 1 dpf (days post fertilization). (D) pU1-Gal4-UAS-GFP labels the myeloid lineage in green. (E) atp6v0a1 expression is in red. (F) Merge.

(G–I) Dorsal view of the wild-type fish head at 3 dpf (days post fertilization). (G) Apo-E-GFP labels microglial cells in green. (H) atp6v0a1 expression in red (I) Merge. In the bottom right corner is an enlargement of an APO-E-positive cell expressing atp6v0a1 mRNA.

Expression Data

Genes:	atp6v0a1a EGFP
Fish:	zf149Tg
Anatomical Terms:	microglial cell myeloid lineage restricted progenitor cell
Stage Range:	Prim-5 to Protruding-mouth

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
