Fig. S1

Forebrain patterning in zic2a morphants at 4s?12s. (A, B) six3b, which marks the eye field and irx1b, which marks the future thalamus, are not affected at 4s (46/47 morphants, 3 exp.). (C, D) rx3, another marker of the eye field and the anterior hypothalamus is not affected at 8s (31/32 morphants, 2 exp.). (E, F) fezf2 marks the forming prethalamus and is not affected at any time between 4s and 12s (12s stage shown, 24/25 morphants, 2 exp.). Embryos are shown in lateral views, anterior to the left.

Expression Data

Genes:	fezf2 irx1b rx3 six3b
Fish:	AB AB + MO3-zic2a
Knockdown Reagent:	MO3-zic2a
Anatomical Terms:	optic primordium optic vesicle presumptive diencephalon thalamus ventral thalamus
Stage Range:	1-4 somites to 10-13 somites
