Fig. S1

Video-Enhanced Nomarski Images of the Mitosis of a Progenitor in the Caudal Hematopoietic Tissue at 4 dpf Around the cell undergoing mitosis (arrows) appear various other progenitors, plus a macrophage (m) and a granulocyte (g) which migrated away between E and F. (A) Prophase; (B) Metaphase; (C) Anaphase A; (D) Anaphase B and telophase; (E) Daughter cells with condensed chromatin and no nucleus yet; (F) Nuclear assembly almost complete; the two daughter cells are still connected by a tether (red arrow), better seen in the lower right inset; note the deformation of a circulating erythrocyte (e) as it bumped in a progenitor, demonstrating that the latter is intraluminal. Ir, iridophore; bar, 10 μm.
