|ZFIN ID: ZDB-FIG-070418-10|
|Stage Range:||Long-pec to Protruding-mouth|
Fig. 7 Regulation of the zebrafish gngT1 expression by otx5 in the pineal gland. The embryos were injected with MO-otx5 and the transcripts were detected by Dig labeled gngT1 probe. (a) Dorsal view of gngT1 expression in the pineal gland. (b) Lateral view of gngT1 expression in the pineal and the retina at 72 hpf. (c) Expression of the GFP in the pineal gland at 72 hpf using the transgenic zebrafish line TG[aanat-2:GFP].
|WT + MO1-otx5||standard conditions||Long-pec||epiphysis||ISH|
ZFIN wishes to thank the journal Gene expression patterns : GEP for permission to reproduce figures from this article.
Please note that this material may be protected by copyright.
Reprinted from Gene expression patterns : GEP, 7(5), Chen, H., Leung, T., Giger, K.E., Stauffer, A.M., Humbert, J.E., Sinha, S., Horstick, E.J., Hansen, C.A., and Robishaw, J.D., Expression of the G protein gammaT1 subunit during zebrafish development, 574-583, Copyright (2007) with permission from Elsevier. Full text @ Gene Expr. Patterns
