FIGURE

Fig. 2

ID

ZDB-FIG-061205-2

Publication

Sidi et al., 2003 - Maternal induction of ventral fate by zebrafish radar

Other Figures

All Figure Page

Back to All Figure Page

Fig. 2

Loss-of-Mrdr function results in down-regulation of early bmp expression. Expression profiles of bmp2b (Left), bmp4 (Center Left), bmp7 (Center Right), and chordin (Right) in uninjected (A?D) and rdr^DN-injected (E?H) early gastrulae (50% epiboly), and in uninjected (I?L) and injected (M?P) embryos at indicated stages of initiation of gene expression. (M, N, and P) rdr^atgMO-injected and (O) rdr^DN-injected are shown. Arrowheads in A and E point to the dorsal (shield) territory of bmp2b expression (24), which, in contrast to the ventrolateral territory, was not affected by rdr^DN. Arrowheads in D and H indicate the limits of chordin expression domain. A?H and I?P are animal pole and lateral views, respectively, dorsal to the right.

Expression Data

Genes:	bmp2b bmp4 bmp7a chrd
Fish:	WT
Anatomical Term:	unspecified
Stage Range:	Sphere to 50%-epiboly

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Proc. Natl. Acad. Sci. USA
