Fig. 4

Comparison of expressions of pcdh10 and pcdh8 in paraxial mesoderm. Embryos were stained by whole-mount ISH for pcdh10 or pcdh8, manually sectioned, and flat-mounted for microscopy. a,b: 12 hours postfertilization (hpf). c,d: 14 hpf. a,c: pcdh10. b,d: pcdh8. Arrows indicate the latest visually segmenting somites. Asterisks indicate the older somites with positive pcdh10 or pcdh8 staining. Plus signs indicate the latest presumptive somites. Opposing arrowheads, adaxial cells; N, notochords. Dorsal views with the rostral to the left. Scale bar = 50 μm.

Expression Data

Genes:	pcdh8 pcdh10b
Fish:	WT
Anatomical Terms:	adaxial cell segmental plate somite
Stage Range:	5-9 somites to 10-13 somites
