Fig. 3

Expression of pcdh10 in zebrafish embryos. Zebrafish embryos were stained by whole-mount in situ hybridization for pcdh10 or myoD. a-f: myoD. g-r: pcdh10. a-l: Dorsal views of the developing somites. m-r: Lateral views. a,g,m, 10 hours postfertilization (hpf); b,h,n, 11.5 hpf; c,i,o, 14 hpf; d,j,p, 16 hpf; e,k,q, 19 hpf; f,l,r, 22 hpf. Closed arrowheads indicate the latest visually segmenting somites. Closed arrows, epiphysis. Open arrowheads, otic vesicles. Open arrows, head mesoderm. Rostral is to the top. Scale bar = 100 μm.

Expression Data

Genes:	myod1 pcdh10b
Fish:	WT
Anatomical Terms:	epiphysis mesoderm paraxial mesoderm segmental plate somite
Stage Range:	Bud to 26+ somites
