Fig. 7

Defects in ectodermal specification and survival in low mutants and in larvae injected with ap2bMO. (A-I) TUNEL labeling of apoptotic cells at 28 hpf is shown in lateral views of the head (A-F) and tail (G-I). (D-F) Co-labeling with TUNEL and the fli1-GFP transgene showing apoptosis lateral to the NCCs in the surface ectoderm (arrows). (J-L) In situ hybridization for nkx2.3 at 28 hpf in dorsal view. Expression is detected in pharyngeal ectoderm and endodermal pouches (arrowheads). b, branchial; h, hyoid; m, mandibular; mf, median fin; n, notochord; ot, otic vesicle; sc, spinal cord. Scale bars: 100 µm.

Expression Data

Gene:	nkx2.3
Fish:	WT tfap2a^ts213/ts213 tfap2a^ts213/ts213 + MO1-tfap2b
Knockdown Reagent:	MO1-tfap2b
Anatomical Terms:	mandibular arch skeleton pharyngeal arch 2 skeleton pharyngeal pouch
Stage:	Prim-5
