Fig. 3 Bmp signaling is not essential for the maintenance of specified liver progenitors. Embryos obtained from outcrossing a hemizygous Tg(hsp70l:dnBmpr-GFP) zebrafish were heat shocked at 22 (A-C,G-I,M-O) or 26 (D-F,J-L,P-R) hpf, harvested at 33 (A-C,G-I), 36 (D-F,J-L) or 38-40 (M-R) hpf, and examined for hhex (A-F), prox1 (G-L) and cp (M-R) expression. The percentage of hemizygous embryos exhibiting a similar expression pattern is indicated in the lower left corner (n=8-10). When embryos were heat shocked at 22 hpf, both hhex and prox1 expression in the liver region (arrows) were greatly reduced in the hemizygous embryos, whereas their expression in other regions (arrowheads) appeared unaffected (B,C,H,I). By contrast, when they were heat shocked at 26 hpf, both hhex and prox1 were clearly expressed in the liver region in all the hemizygous embryos (E,F,K,L, arrows). However, hhex and prox1 expression in the liver region (arrows) was somewhat reduced compared with wild-type siblings, whereas hhex expression in the pancreatic islet and prox1 expression in the interrenal primordium (arrowheads) appeared unaffected (D-F,J-L). Hepatocyte differentiation, assessed by cp expression, barely occurred in the hemizygous embryos heat shocked at 22 hpf (N,O, arrows), and was clearly reduced in those heat shocked at 26 hpf (Q,R, arrows). All images, except insets, are dorsal views, anterior left. Insets are side views, anterior left.
