Fig. 2

prkacαa neuronal expression patterns. Brightfield images of zebrafish embryos processed for in situ hybridization. (A–C) Whole-mount lateral, (A′-C′) whole-mount dorsal. Brightfield sections (A″-C″) forebrain, (A‴-C‴) midbrain and (B‴‘-C‴‘) hindbrain. Embryos were imaged at different developmental time points. (A-A‴) 24 hpf, (BB‴‘) 48 hpf, (CC‴‘) 72 hpf. Lines in (A–C) indicate locations of the sections shown at that time-point. Hpf-hours post fertilization, NR-neural retina, OV otic vesicle, E−ear, FB fin bud, DT-dorsal thalamus, TeO optic tectum, Popre-optic region, PTv-ventral part of the posterior tuberculum, INL-inner nuclear layer, MB- mid brain, VT-ventral thalamus, RGC- retinal ganglion cell layer, MO- medulla oblongata, n.s-non-specific. Inset shows sense probe control.

Expression Data
Gene:
Fish:
Anatomical Terms:
Stage Range: Prim-5 to Protruding-mouth

Expression Detail
Antibody Labeling
Phenotype Data

Phenotype Detail
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 31, Emerson, S.E., Grebber, B.K., McNelllis, M., Orr, A.R., Deming, P.B., Ebert, A.M., Developmental expression patterns of protein kinase A catalytic subunits in zebrafish, 1-6, Copyright (2018) with permission from Elsevier. Full text @ Gene Expr. Patterns
